Description
ENGINE
ENGINE TYPE
Single cylinder, liquid cooled, 4-stroke, SOHC, 4-valve
DISPLACEMENT
400cc
MAX POWER
30 HP @ 7200 RPM
MAX TORQUE
24 LB-FT @ 6000 RPM
FUEL SYSTEM
Bosch® EFI
COOLING SYSTEM
Liquid cooled
DRIVE
2WD/4WD/4WD lock
TRANSMISSION
CVTech® Automatic P/R/N/H/L
STARTER
Electric
DIMENSIONS & WEIGHT
LENGTH X WIDTH X HEIGHT
80” x 44” x 45”
WHEEL BASE
50”
SEAT HEIGHT
20”
CURB WEIGHT
732 lbs.
GROUND CLEARANCE
9.8”
RACK CAPACITY
Front/Rear: 75 lbs. / 132 lbs.
FUEL TANK CAPACITY
4.5 gal.
CHASSIS
SUSPENSION
Front/Rear: Double A-arm independent
WHEELS
Front/Rear: 12” Steel
TIRES
Front: 24” x 8” x R12 / Rear: 24” x 10” x R12
SHOCKS
Front/Rear: Spring pre-load adjustable, oil damped
BRAKING
Front/Rear: Hydraulic disc with parking brake
STANDARD EQUIPMENT
HITCH/RECEIVER
2”
TOWING CAPACITY
1350 lbs.
